Pedal Replacement
About
This procedure provides instruction to remove and install the Pedals.
The pedals are dual-sided SPD
1
®
compatible pedal attached to oversized crank arms util-
izing the patented Morse taper connections.
Available Movies
(Internet Only)
Pedal Replacement tutorial video.
Specifications
System Component Specification
Pedal fastener Torque
2
33 ft-lb (45 N•m)
Specialized Tools
Tool Part Number Qty
Crank Extractor
(used to remove pedal)
X-Tools Crank Extractor)
(1)
or similar 1
Procedure
Review entire procedure before starting.
CAUTION:Be careful not to scratch or dent bike with tools during the removal/in-
stallation process.
1
speed
2
Torque is a measure of the force that can cause an object to rotate about an axis. Bolt/nut
example: 5 NM torque is equivalent to 5 newton's of force applied one meter from the center
of the bolt, 6 ft-lb is equivalent to 6 lbs of force applied 1 foot away from the center of the
bolt.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 121
