Service and Diagnostic Menus
(Spinner® Chrono
1
™ Power models only)
About
In addition to the primary workout display information, the Spinner® Chrono™ console has
a service/setup mode providing access to the club setup parameter menus, the bike inform-
ation menus, the current operating information menus, and to the service diagnostic test
menus:
l
Club Parameters: Use Club Parameter settings to choose the type of information
you want exercisers to see on the console while working out.
l
Informational Settings:The Information Settings contain the information required
when you contact Precor Customer Support including serial numbers, software pro-
gram versions, odometer, and model numbers.
l
Operational Information: The operating Torque
2
, WATTS, and RPM values.
l
Service Tests: Perform tests to help you troubleshoot systems including torque,
WATTS, RPM, battery, generator and console display.
l
Error Log: View the detected error event codes, see "Error Log" on page156.
USB
3
Port
The console USB port is used for program updates, system settings cloning between con-
soles, and to download system information and error log data.
Service/Setup Mode Access
Service/Setup Mode Access
1
Spinner® Chrono™ Power bike.
2
Torque is a measure of the force that can cause an object to rotate about an axis. Bolt/nut
example: 5 NM torque is equivalent to 5 newton's of force applied one meter from the center
of the bolt, 6 ft-lb is equivalent to 6 lbs of force applied 1 foot away from the center of the
bolt.
3
Short for Universal Serial Bus, is an industry standard developed in the mid-1990s that
defines the cables, connectors and communications protocols used in a bus for connection,
communication, and power supply between computers and electronic devices.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 146
6 Troubleshooting
Service and Diagnostic Menus
