Precor SPINNER CHRONO POWER User Manual

Handlebar Assembly Replacement
About
This procedure provides instruction to remove and install the Handlebar Assembly.
Procedure
Review entire procedure before starting.
Removal Instructions
1. (Spinner® Chrono
1
™ Power models only)
Remove the four 4 mm (4x) hex key bolts and remove the console backplate cover.
Disconnect the data COMM cable from the console and set the console aside, see
the "SPINNER
®
CHRONO™ CONSOLE" Operator's Guide.
2. Remove the rear handlebar post slider end cap by removing the two 2.5 mm hex key
bolts. Retain for installation.
1
Spinner® Chrono™ Power bike.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 100
5 Replacement Procedures
Handlebar Assembly Replacement
