LPCA Status LEDs
ID LED Description
Logic microprocessor ON (flashes green)
3.3 Vdc supply (red)
5 Vdc supply (red)
9 Vdc supply (red)
(while pedaling or AC/DC adapter plugging in)
Battery Charging (red)
lON ≥ 55 rpm (charging battery)
lOFF ≥ 55 rpm and battery fully charged
lOFF < 55 rpm
Procedure
Review entire procedure before starting.
CAUTION:Electronic components can easily be damaged by electrostatic dis-
charge (ESD
1
). Always use properly grounded anti-static wrist-strap and anti-static
mat when handling or servicing printed circuit boards.
Removal Instructions
1
Electrostatic Discharge or Electrostatic Sensitive Device.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 114
5 Replacement Procedures
LPCA board Replacement
