Primedic DefiMonitor XD

To Next Page

To Previous Page

Depiction of the current time function

98 / 116

DefiMonitor XD 21324 / GB / K05

METRAX GmbH

I / A

360 Joule @ 50 Ohm

360 Joule @ 75 Ohm

360 Joule @ 100 Ohm

I / A

360 Joule @ 125 Ohm

360 Joule @ 150 Ohm

360 Joule @ 175 Ohm
