■ Raising and lowering the blade
□
To raise the blade, pull the joystick
backwards (float switch to off).
□ To lower the blade, push the joystick
forwards (float switch to off).
■ Tilting the blade
□
Tilt left: To tilt the blade in the left di-
rection, move the joystick towards the
left side.
□ Tilt right: To tilt the blade in the right
direction, move the joystick towards
the right side.
□ Neutral: This position holds the blade
at the desired height and angle. To
select Neutral, leave joystick cen-
tered.
■ Blade Angler (push-button S1 (BISON X)
or joystick switch D)
□
Angle Left: To angle the blade in the
left direction, press and hold push-
button S1 and push the joystick to-
wards the left side. If using the joy-
stick on joystick, simply push the joy-
stick switch D to the left.
□ Angle Right: To angle the blade in
the right direction, press and hold
push-button S1 and push the joystick
towards the right side. If using the
joystick on joystick, simply push the
joystick switch D to the right.
□ Neutral: This position holds the blade
at the desired roll and angle. To se-
lect Neutral, leave the joystick or joy-
stick switch centered.
■ Blade Roll Control (push-button S1 (BI-
SON X) or joystick switch D)
□
Roll Down: To roll (or curl) down the
blade, press and hold push-button S1
and push the joystick forwards. If us-
ing the joystick on joystick, simply
push the joystick switch D forwards.
□ Roll Up: To roll (or curl) up the blade,
press and hold push-button S1 and
pull the joystick backwards. If using
the joystick on joystick, simply pull
the joystick switch D backwards.
Snow groomer BISON
Operating and Maintenance Manual
BISON 908930245 - 30367
5 - Vehicle
61 (255)
