Installing the Access Point
Installation Procedures
LAN. Each wireless PC in a BSS can communicate with any computer in its
wireless group, or access other computers or network resources in the wired
LAN through the access point.
The infrastructure configuration extends the accessibility of wireless PCs to
the wired LAN and can be used for access to central network resources, or
for connections between mobile workers, as shown in the following figure.
Figure 2-1. Infrastructure Wireless LAN
Desktop PC
Access Point 10ag
File
Server
Switch
Desktop PC
Wireless Client
Notebook PC
Wireless Client
Wired LAN Extension
to Wireless Clients
and Devices
Network Printer
Wireless Device
