4.7.3. STAGE Set and read the status of Load
[STATe:] LOAD {SP}{ONOFF}
Syntax: [STATe:] LOAD {SP}{ONOFF}{;NL}
[STATe:] LOAD {?}{;NL}
Purpose:Set and read the status of Sink Current or not
Description:This command is used for setting the status of Sink Current . When setting it
to ON, the Load is going to sink current from appliance. When setting it to
OFF, the Load would not act.
[STATe:] MODE {SP}{CCCRCVCP}
Syntax: [STATe:] MODE {SP}{CCCRCVCP}{;NL}
[STATe:] MODE {?}{;NL}
Purpose:Set and read the mode of LOAD
Description：Load is acting under these four modes as the following TABLE 4-9. When
reading the Loading Operation mode, the return value 0│1│2│3│4 are
meant to be CC│LIN│CR│CV│CP
Mode CC LIN CR CV CP
(value)
0
1
2
3
4
3270 series V V V V V
Table 4-9 module for each series
[STATe:] PRESet {SP}{ONOFF}
Syntax: [STATe:] PRESet {SP}{ONOFF}{;NL}
[STATe:] PRESet {?} {;NL}
Purpose:Set the left or right digit multi-function meter to display the programming load
level.
Description:This command is for select the left 5 digit LCD display to show current
setting or DWM.
Pres ON:To select the LCD display to shows current setting
Pres OFF:To select the LCD Display is 〝DWM〞
[STATe:] SENSe{SP}{ONOFF }
Syntax: [STATe:] SENSe{SP}{ONOFF }{;NL}
[STATe:] SENSe {?} {;NL}
Purpose：Set and read the Load voltage to read whether is carried by the VSENSE or
not.
Description：This command is for setting the Load voltage to read whether is carried by
VSENSE or INPUT Connector. When setting for ON, the voltage is got
from VSENSE, and setting for OFF, the voltage is got from INPUT
Connector.
[STATe:] LEVel {SP}{AB} or LEV {SP}{AB}
Syntax: [STATe:] LEVel {SP}{AB }{;NL}
[STATe:] LEVel {?} {;NL}
[STATe:] LEV{SP}{AB}{;NL}
