Prodigit 3270 Series User Manual

3270 Series Operation Manual 13
1-6. Specifications 2
MODEL
3270
3271
3272
3273
3274
Power (W)
3750 W
2800W
1875 W
3750 W
2800W
Current(Ampere)
37.5 Arms / 112.5Apeak
28 Arms / 84Apeak
18.75 Arms / 56.25Apeak
28 Arms / 84Apeak
18.75 Arms / 56.25Apeak
Voltage(Volt)
50~350Vrms / 500Vdc
FREQUENCY Range DC,40~440Hz(CC,CP Mode) , DC~440Hz(LIN,CR,CV Mode)
PROTECTIONS
Over Power Protection
≒ 3937.5Wrms or Programmable
≒ 2940Wrms or Programmable
≒ 1968.75Wrms or Programmable
≒ 3937.5Wrms or Programmable
≒ 2940Wrms or Programmable
Over Current Protection ≒ 39.375 Arms, or Programmable ≒
29.4 Arms or Programmable
≒ 19.687 Arms or Programmable ≒
29.4 Arms or Programmable
≒ 19.687 Arms or Programmable
Over Vlotage Protection
≒ 367.5 Vrms/525Vdc
Over Temp. Protection Yes
OPERATION MODE
Constant Current Mode for Sine-Wave
Range 0~37.5A 0~28A 0~18.75A 0~28A 0~18.75A
Resolution 0.625mA/16bits 0.5mA/16bits 0.3125mA/16bits 0.5mA/16bits 0.3125mA/16bits
Accuracy ±（ 0.1% of setting ＋ 0.2% of range ）@ 50/60Hz , ± 0.5% of（ setting ＋ range ）
Linear Constant Current Mode for Sine-Wave, Square-Wave or Quasi-Square Wave, PWM Wave
Range
0~37.5A
0~28A
0~18.75A
0~28A
0~18.75A
Resolution 0.625mA/16bits 0.5mA/16bits 0.3125mA/16bits 0.5mA/16bits 0.3125mA/16bits
Accuracy ±（ 0.1% of setting ＋ 0.2% of range ）@ 50/60Hz , ± 0.5% of（ setting ＋ range ）
Constant Resistance Mode
Range 1.6 ohm～32K ohm 2.0 ohm～40K ohm 3.2 ohm～64K ohm 2.0 ohm～40K ohm 3.2 ohm～64K ohm
Resolution*1 0.010416mS/16bits 0.0083333mS/16bits 0.0052083mS/16bits 0.0083333mS/16bits 0.0052083mS/16bits
Accuracy
±0.2% of （setting ＋ range）@ 50/60Hz , ±（ 0.5% of setting ＋ 2% of range ）
Constant Voltage Mode
Range 50~350Vrms / 500Vdc
Resolution 0.1V
Accuracy ±(0.1% of reading ＋ 0.1% of range)
Constant Power Mode
Range 3750W 2800W 1875W 3750W 2800W
Resolution 0.1W 0.1W 0.1W 0.1W 0.1W
Accuracy
±(0.1% of reading ＋ 0.1% of range)
CREST FACTOR (CC & CP MODE ONLY)
Range
√ 2~5
Resolution
0.1
Accuracy (0.5％ / Irms) + 1％F.S.
POWER FACTOR (CC & CP MODE ONLY)
Range 0~1 Lag or Lead
Resolution 0.01
Accuracy
1％F.S.
TEST MODE
UPS Efficient Measurement
Non-Linear Mode
Operating Frequency Auto ; 40~440Hz
Current Range
0~37.5A
0~28A
0~18.75A
0~28A
0~18.75A
PF Range 0~1
MEASURING EFFICIENCY FOR PV
SYSTEMS, POWER
CONDITIONERS for THD 80%
Resistive + Non-Linear Mode
Operating Frequency
Auto ; 40~440Hz
Current Range 0~37.5A 0~28A 0~18.75A 0~28A 0~18.75A
Resistive Range 1.6 ohm～32K ohm 2.0 ohm～40K ohm 3.2 ohm～64K ohm 2.0 ohm～40K ohm 3.2 ohm～64K ohm
UPS Back-Up function(CC,LIN,CR,CP)
UVP (VTH) 50~350Vrms / 500Vdc
UPS Back-Up Time 1~99999 Sec. (>27H)
Battery Discharge function(CC,LIN,CR,CP)
UVP (VTH)
50~350Vrms / 500Vdc
Battery Discharge Time 1~99999 Sec. (>27H)
UPS Transfer Time
Current Range 0~37.5A 0~28A 0~18.75A 0~28A 0~18.75A
UVP (VTH)
2.5V
Time range 0.15mS~999.99mS
