14 PRODIGIT
Fuse Test mode
Max. Current
Turbo OFF
37.5Arms
28.0Arms
18.75Arms
28.0Arms
18.75Arms
Turbo ON 75.0Arms (x2)
*3
56.0Arms (x2) *3 37.5Arms (x2) *3 56.0Arms (x2) *3 37.5Arms (x2) *3
Trip & Non-Trip Time
Turbo OFF
0.1~9999.9sec.
Turbo ON 0.1~1.0sec.
Meas. Accuracy ±0.003 Sec.
Repeat Cycle 0~255
Short/OPP/OCP Test Function
Short Time
Turbo OFF
0.1S ~ 10Sec. Or Cont.
Turbo ON 0.1S ~ 1Sec
OPP/OCP Step Time
Turbo OFF 100ms
Turbo ON 100ms, up to 10 Steps
OCP Istop
Turbo OFF 37.5Arms 28.0Arms 18.75Arms 28.0Arms 18.75Arms
Turbo ON 75.0Arms 56.0Arms 37.5Arms 56.0Arms 37.5Arms
OPP Pstop
Turbo OFF 3750W 2800W 1875W 3750W 2800W
Turbo ON 7500W 5600W 3750W 7500W 5600W
Programmable Inrush current simulation: Istart - Istop / Tsep
Istart, Inrush Start Current 0~75A 0~56A 0~37.5A 0~56A 0~37.5A
Inrush Step time 0.1mS~100mS
Istop, Inrush stop current 0~37.5A 0~28A 0~18.75A 0~28A 0~18.75A
Programmable Surge current simulation: S1/T1 - S2/T2 - S3/T3
S1 and S2 Current
0~75A
0~56A
0~37.5A
0~56A
0~37.5A
T1 and T2 Time 0.01S~0.5Sec.
S3 Current 0~37.5A 0~28A 0~18.75A 0~28A 0~18.75A
T3 Time
0.01S ~ 9.99Sec. Or Cont.
MEASUREMENTS
VOLTAGE READBACK A METER
Range
500V
Resolution 0.01V
Accuracy ±0.05% of (reading range)
Parameter Vrms,V Max/Min,+/-Vpk
CURRENT READBACK A METER
Range 18.75Arms/37.5Arms 14Arms/28Arms 9.375Arms/18.75Arms 14Arms/28Arms 9.375Arms/18.75Arms
Resolution
0.4mA/0.8mA
0.3mA/0.6mA
0.2mA/0.4mA
0.3mA/0.6mA
0.2mA/0.4mA
Accuracy ±0.05% of reading range@ 50/60Hz , ±0.2% of reading range
Parameter Irms,I Max/Min,+/-Ipk
WATT READBACK W METER
Range 3750W 2800W 1875W 3750W 2800W
Resolution 0.0625W 0.05W 0.03125W 0.0625W 0.05W
Accuracy ±0.1% of reading range
VA METER Vrms×Arms Correspond To Vrms and Arms
Power Factor METER
Range
+/- 0.000~1.000
Accuracy ±(0.002±(0.001/PF)*F)
Frequency METER(V)
Range DC,40~440Hz
Accuracy 0.1%
Other Parameter METER
VA, VAR, CF_I, Ipeak, Imax., Imin. Vmax., Vmin., IHD, VHD, ITHD, VTHD
OTHERS
Start up loading Yes , Power on loading during Inverter / UPS start up
Load ON / OFF Angle
0 ~ 359 degree can be programmed for the angle of load ON and load OFF loading
Half cycle and SCR/TRIAC loading Postive or Negative half cycle, 90˚ Trailing edge or Leading edge current waveform can be programmed
Master/Slave( 3 phase or Parallel application) Yes, 1 master and upto 7 slave units
External programming input(OPTION)
F.S / 10Vdc, Resulotion 0.1V
External SYNC input
TTL
Vmonitor Isolated
±500V / ±10V
Imonitor Isolated
±112.5Apk / ±10Vpk ±84Apk / ±10Vpk ±56.25Apk / ±10Vpk ±84Apk / ±10Vpk ±56.25Apk / ±10Vpk
Interface (OPTION) GPIBRS-232LANUSB
Power consumption
150VA
Operation Temperature *2
0 ~ 40
Current of input impedance(mA) @ 50/60Hz ; @400Hz ~V*0.6 ; ~V*4.4 ~V*0.45 ; ~V*3.3 ~V*0.3 ; ~V*2.2 ~V*0.4 ; ~V*2.95 ~V*0.3 ; ~V*2.2
Dimension( H x W x D ) 177 x 440 x 558 mm 177 x 440 x 558mm 177 x 440 x 558 mm 177 x 440 x 558 mm 177 x 440 x 558 mm
Weight
33.5Kg 27.5Kg 21.5Kg 33.5Kg 27.5Kg
*1 ms (millisiemens) is the unit of conductance(G), one siemens equal to 1/Ω
*2 Operating temperature range is 0~40, all specification apply for 25℃±5, Except as noted
* All specifications subject to change without notice.
Table 1-1A 3270 Series Specification
