12 PRODIGIT
1-4. Option
1.4.1. GPIB+RS232 interface
1.4.2. RS232 interface
1.4.3. GPIB interface
1.4.4. USB interface + USB DRIVER CD
1.4.5. LAN interface + LAN DRIVER CD
1.4.6. GPIB cable 1 M
1.4.7. GPIB cable 2 M
1.4.8. USB TYPE A TO TYPE B cable 1.8 M.
1-5. Specifications 1
Table 1-1 3270 Series Specifications
AC INPUT
LINE
100Vac~230Vac ± 10%
FREQUENCY
50/60 Hz ±3Hz
PROTECT FUSE
2A/250V (5*20mm)
MAX.POWER
CONSUMPTION
150VA
Model
Power
Voltage
Current
Dimension(HxWxD)
WEIGHT
3270 3750W 350V 37.5A 177 mm x 440 mm x 558 mm 33.5 Kg
3271 2800W 350V 28A 177 mm x 440 mm x 558 mm 27.5 Kg
3272 1875W 350V 18.75A 177 mm x 440 mm x 558 mm 21.5 Kg
3273 3750W 350V 28A 177 mm x 440 mm x 558 mm 33.5 Kg
3274 2800W 350V 18.75A 177 mm x 440 mm x 558 mm 27.5 Kg
