Prodigit 3270 Series User Manual

3270 Series Operation Manual 83
MEAS:CF {?}{;NL}
MEAS:FREQ {?}{;NL}
MEAS:V_THD {?}{;NL}
MEAS:I_THD {?}{;NL}
MEAS:V_HARM {?}{;NL}
MEAS:I_HARM {?}{;NL}
HARM {SP} {NR1} {
;
│NL}
1~50;select Harmonic step
SYNC {SP}{ON│OFF} {
;
│NL}
MEAS:TYPE{SP} {RMS|PEAK|MAX|MIN} {; NL}
REMOTE {;NL}
RS232/USB/LAN command
LOCAL{; NL}
RS232/USB/LAN command
Table 3-1
3.5.1.14. 3PH Mode use the command：In addition 3PH Mode can use the "GLOB:"
command in Table 3-3.
AUTO SEQUENCE Set the command
NOTE
RETURN
FILE {SP} {n}{
;
 NL}
n=1~9 1~9
STEP {SP} {n} {
;
NL}
n=1~32
1~32
TOTSTEP {SP} {n}{
;
NL}
Total step n=1~32 1~32
SB {SP} {n} {
;
NL}
LOAD State n=1~150
1~150
TIME {SP} {NR2} {
;
NL}
100~9999(ms) 100~9999(msec)
SAVE {
;
NL}
Save “File n” data
REPEAT {SP} {n} {
;
NL}
n=0~9999 0~9999
RUN {SP} {F} {n} {;NL}
n=1~9
AUTO REPLY
“PASS” or “FAIL:XX”
(XX=NG STEP)
BEEP{SP}{ON│OFF}{
;
│NL}
SET BUZZER ON/OFF
Table 3-2 AUTO SEQUENCE 3PH MODE can not be used command
COMMAND
RETURN
Master,Slave1,Slave2,
GLOB
:
MEAS: CURR {?}{
;
NL}
###.####,###.####,###.####,
GLOB
:
MEAS: VOLT {?}{
;
NL}
###.####,###.####,###.####,
GLOB
:
MEAS: POW {?}{
;
NL}
###.####,###.####,###.####,
GLOB
:
MEAS: VAR {?}{
;
NL}
###.####,###.####,###.####,
GLOB
:
MEAS: VA {?}{
;
NL}
###.####,###.####,###.####,
GLOB
:
MEAS: V_THD {?}{
;
NL}
###.####,###.####,###.####,
GLOB
:
MEAS: I_THD {?}{
;
NL}
###.####,###.####,###.####,
GLOB
:
MEAS: V_HARM {?}{
;
NL}
###.####,###.####,###.####,
GLOB
:
MEAS: I_HARM {?}{
;
NL}
###.####,###.####,###.####,
GLOB
:
MEAS: PF {?}{
;
NL}
###.####,###.####,###.####,
GLOB
:
MEAS: CF {?}{
;
NL}
###.####,###.####,###.####,
GLOB
:
MEAS: FREQ {?}{
;
NL}
###.####,###.####,###.####,
Table 3-3 3PH MODE GLOB command
