Figure CP Set 9900W
3.5.1.12. Master Mode operation except CC / CR / CV / CP MODE, The following functions
Will be disable.
• Recall/Store Disable.
• Short, OCP, OPP Disable.
• External I/O Disable
3.5.1.13. REMOTE operating： Master Mode can use the command as follows
SETTING PRESET NUMERIC COMMAND REMARK
MODE {SP} {CC│LIN│CR│CP} {
;
NL}
OCL{SP} {NR2} {;NL}
OPL{SP} {NR2} {;NL}
SENS {SP} {ON│OFF│1│0} {
;
│NL}
0
:
OFF
,
1
:
ON
ON:ANG{SP} {NR2} {;NL}
0~359
OFF:ANG{SP} {NR2} {;NL}
0~359
CC CURR:{A B} {SP} {NR2}{;NL}
LIN:{A B} {SP} {NR2}{;NL}
CR RES:{A B} {SP} {NR2}{;NL}
CP:{A B} {SP} {NR2}{;NL}
MODE {SP} {CC│LIN│CR│CP} {
;
│NL}
LEV {SP} { A│B│0│1} {
;
│NL}
FREQ {SP} {AUTO│NR2} {
;
│NL}
PF {SP} {NR2} {
;
│NL}
CF {SP} {NR2} {
;
│NL}
1.4~5.0 ;1.3(TRAIL),1.2(
LOAD {SP}{ON│OFF│1│0} {
;
│NL}
MEAS:CURR {?}{;NL}
MEAS:VOLT {?}{;NL}
MEAS:POW {?}{;NL}
MEAS:VA {?}{;NL}
MEAS: VAR {?}{;NL}
MEAS: PF {?}{;NL}
Master boost
Display
Slave 1
Display
Slave 2
Display
