32 PRODIGIT
3.3.16.2. Linear Constant Current (LIN) mode:
The A and B levels of load current can be preset at right lower 5 digit
LCD. the "A" LED will be lit indicating the setting value is amps.
3.3.16.3. Constant Resistance (CR) mode:
The A and B levels of load resistance can be preset on the right lower 5
Digit LCD. The "Ω" LED will be lit indicating the setting value is ohms.
3.3.16.4. Constant Voltage (CV) mode:
The A and B levels of load voltage can be preset on the right lower 5
Digit LCD. The “V" LED will be lit indicating the setting value is volts.
3.3.16.5. Constant Power (CP) mode:
The A and B levels of load power can be preset on the right lower 5 digit
LCD. The "W" LED will be lit indicating the setting value is watts.
3.3.17. key
The LIMIT button allows the user to set left and right thresholds for voltage, current
Or power. These threshold settings are used in conjunction with the NG function to
Flag when the load is operating outside the desired limits
Each press of the LIMIT key enables a different value to be entered. On first press
Of the LIMIT key the button will illuminate and V-Hi will be displayed on the right
LCD. The setting is made with the rotary knob and can be read from the right LCD
during setting. The setting sequence is shown below:
V_Hi (DVM upper limit)
V_Lo (DVM lower limit)
I_Hi (DAM upper limit)
I_Lo (DAM lower limit)
W_Hi (DWM upper limit)
W_Lo (DWM lower limit)
VA Hi
VA Lo
OPL
OCL
NG OFF/ON (No Good Flag)
LIMIT setting function OFF
