3270 Series Operation Manual 35
Setting OPL, the right upper 5 digit monitor display ”OPL” and right lower
monitor display upper limit of the voltmeter with the unit as "W", The OPL set
range from 0.1W to 3937.5W step 0.1W by rotating the Setting knob.
Setting OCL, the right upper 5 digit monitor display ”OCL” and right lower
monitor display upper limit of the voltmeter with the unit as "A", The OCL set
range from 0.001 A to 39.375A step 0.001A by rotating the Setting knob.
Setting NG ON/OFF, When exceed VH, VL, IH, IL, WH, WL, VAH, VAL One
of these Whether NG on LCD display.
CC mode, press limits key to set the V-Hi and V-Lo voltage upper and lower
limits of the GO / NG.
