Prodigit 3270 Series User Manual

80 PRODIGIT
Figure CR Set 3.6666Ω
Figure CP Set 3300W
Figure CV Set 110V
3.5.1.11. Master boost Manual operation：
(3270 MASTER boost/SLAVE model the following is example)
PRESET Setting: CC/LIN/CR/CV/CP Mode as Figure, CC setting 30A=Master 30A
+ Slave 1 10A+ Slave 2 10A, LIN setting 30A=Master 30A + Slave 1 10A+ Slave 2
10A, CR: 800Ω=Master//Slave1//Slave2=800Ω//2400Ω//2400，CP:9900W=Master
9900W+Slave 1 3300W + Slave 2 3300W.
Slave1
Display
Slave2
Display
Master 3ph
Display
Slave1
Display
Master 3ph
Display
Slave2
Display
Master 3ph
Display
Slave1
Display
Slave2
Display
