20 Wear parts for S3Cb
Refer also to the previous chapter.
20.1
Standard
Spare part Order no.
HMI wall bracket 1036683
HMI protective film 1083680
20.2 Physiological safety
Tab. 22: Scope of delivery with PVT material version
1 x diaphragm, 2 x valve balls, 1 x suction valve complete, 1 x discharge valve complete
1 x elastomer sealing set (EPDM)
2 x ball seat housings, 2 x ball seat discs, 4 x composite seals
1x sealing washer (for bleed valve or relief valve)
Tab. 23: Scope of delivery with SST material version
1 x diaphragm, 2 x valve balls
2 x cover rings
4 x composite seals
1x sealing washer (for bleed valve or relief valve)
Tab. 24: Spare parts kits PVT (liquid ends)
Liquid end Types 120145, 120190, 120270
FM 330 1046478
Tab. 25: Spare parts kits SST (liquid ends)
Liquid end Types 120145, 120190, 120270
FM 330 1046479
FM 330 with 2 complete valves 1046480
Material version Liquid end Suction / pressure
connector
Seals* / ball seat Balls Integrated bleed
valve or relief
valve
PVT PVDF PVDF PTFE / PVDF Glass PVDF / EPDM
SST Stainless steel
1.4404
Stainless steel
1.4581
PTFE / PVDF Stainless steel
1.4404
Stainless steel /
EPDM
* Metering diaphragm is PTFE-coated; seals are PTFE composite seals
HMI spare parts
Spare parts kits
Ordering information
Wetted materials – only with the design
"Physiological safety with regard to wetted
materials"
Wear parts for S3Cb
106
