4. To run through the figures again, if necessary (possibly because of
an incorrect figure), when you get to the last figure press
[Priming]
again - see above Figure, point c).
ð
Now you can start from the beginning again.
Press the
[Clickwheel]
1x.
ð
The software saves the entry.
8.2 Checking adjustable variables
Before adjusting the pump, you can check the current settings of the
adjustable variables:
Simply turn the
[Clickwheel]
if the pump is showing a continuous
display.
ð
Each time the
[Clickwheel]
engages when you turn it, you will
see a different continuous display.
The number of continuous displays depends on the iden‐
tity code, the selected operating mode and the con‐
nected additional devices – see overview of "Continuous
displays" in the appendix.
The lowest line of a continuous display shows different information (which
cannot be adjusted in the secondary display) - see "Continuous displays
and secondary displays" overview in the appendix.
You can access secondary displays via any continuous display as follows:
1. Press the
[Clickwheel]
for 3 seconds.
ð
A frame appears around the secondary display.
2. Providing there is a frame, you will see a different secondary display
each time the
[Clickwheel]
engages when turned.
When you reach the secondary display you wish, leave the
[Clickwheel]
and wait briefly.
8.3 Changing to Setting mode
In a continuous display, if you press
‘Menu’
, the pump in Setting
mode changes to
‘Menu’
. For more information refer to the following
chapter entitled "Set up / Menu".
If under
‘Access protect.’
only
‘Menu’
or
‘All’
has been set up (top right
lock symbol), then after pressing the
[Clickwheel]
, first enter the
‘Password’
.
Confirming adjustable variables
Continuous displays
Secondary displays
Basic set-up principles
44
