17 Dimensional drawings
–
Compare the dimensions on the dimension sheet
and pump.
– All dimensions are in mm.
HMI and wall bracket
2
105.1105.1
72.5
156.7
160
121
48
21.5
6.5
4.54.5
P_SI_0192_SW
Fig. 42: Dimensions in mm
Dimensional drawings
