16.5.4 Degree of Protection and Safety Requirements
Protection against contact and humidity:
IP 65 in accordance with IEC 529, EN 60529, DIN VDE 0470 Part 1
A CAN plug or the supplied sealing cap must always be
plugged into the CAN port for the HMI.
Degree of protection:
1 - mains power connection with protective earth conductor
16.6 Installation height
Data Value Unit
Maximum installation height*: 1000 m above
standard
zero
* with standard pumps: Fit at higher installation heights at your own risk.
with ATEX pumps: We urgently advise that you contact a specialist for
ATEX motors at higher installation heights!
16.7
Electrical connection
The electrical data do not relate to the motor, but the
pump, which is connected as a whole unit.
For the motor electrical data use the motor data sheet in
the appendix.
Identity code specification "power supply" - "U": 100 - 230 V ± 10%, 50/60
Hz
Data Value Unit
Capacity 420 W
Max. starting current 8.5 A
Electrical data at 100 V
Data Value Unit
Effective current 8.3 A
Switch on peak current, (for approx. 100
ms)
4 A
Electrical data at 230 V
Data Value Unit
Effective current 3.4 A
Switch on peak current, (for approx. 100
ms)
8 A
Degree of protection
Safety Requirements
Electrical data S3Cb pump
Technical data
89
