The pump only shows the metering volume and the
capacity in the calibrated state in l or l/h or in gal or
gal/h.
4.2 Key functions
Key Application In the continuous displays In the menu
[Back]
press - Move back to the previous menu
point (or a continuous display) -
without saving
[STOP/
START]
press Stop pump, Stop pump,
Start pump Start pump
[Menu]
press Move to the menu Move back to a continuous display
[Priming]
press Priming * Priming *
[Clickwheel]
press Start batch (only in
‘Batch’
operating
mode),
Acknowledge errors
Move to next menu option (or a
continuous display)
Confirm entry and save
[Clickwheel]
turn Switch between the continuous dis‐
plays
Change figure or change selection
* When priming the pump does not run at maximum
stroke rate.
If
[Priming] is pressed in ‘Stop’ state, then [Priming]
has top priority as long as the button is pressed.
Refer to the "Set-up basics" chapter to adjust figures
Overview of equipment and control elements
17
