Fig. 5: Control elements for HMI Sigma X Control type
1 LCD screen
2
[Menu] key
3
Clickwheel
4
[Priming] key
5
[STOP/START] key
6
[Back] key
7 "Bluetooth active” display (blue)
8 Fault indicator (red)
9 Warning indicator (yellow)
10 Operating indicator (green)
P_SI_0193_SW
6
7
543
2
1
8
Fig. 6: Connector cover control elements
1 Relay and mA-output (option)
2
Slot for optional module (PROFIBUS
®
, ...)
3 "Diaphragm rupture" socket
4 "External control" terminal
5 "Metering monitor" terminal
Overview of equipment and control elements
