Sigma X Control type - Sigma/ 3 - S3Cb
Design
0
with ProMinent
®
logo
1
without ProMinent
®
logo
N Seal according to NEMA 4x
Electric power supply
U 1-phase, 100-240 V, 50/60 Hz
Cable and plug
A 2 m European
B 2 m Swiss
C 2 m Australian
D 2 m USA
Relay
0 no relay
1 Fault indicating relay (230V - 8A)
3 Fault indicating relay + pacing relay (24V
- 100mA)
8 0/4-20 mA analogue output + fault indi‐
cating / pacing relay (24V - 100mA)
Control version
0 Manual + external contact with
PulseControl + timer
1 Manual + external contact with
PulseControl + analogue +
metering profiles
2 Manual + controller + PulseControl
+ analogue + dosing profile +
extreme profile
5 as 1 + timer
6
as 1 + PROFIBUS
®
DP interface
(M12 plug)
7 as 1 + CANopen (M12 plug) **
Overload shut-down
0 without overload shut-down
Operating unit (HMI)
0 HMI (0.5 m cable)
4 HMI + 2 m cable
5 HMI + 5 m cable
6 HMI + 10 m cable
X without HMI
Safety options
0 Metering monitor,
dynamic, without
access control
Identity code
6
