3. Place the Vess A6000 onto the rails.
• At least two persons are required to safely lift the system.
• Lift the Vess A6000 itself. Do not lift the system by its brackets.
Rails installed and
tightened
Brackets
Vess system
Placing the system onto the rack rails
Rail ends attach on the
outside of the front and
rear rack posts
Rail ends aach to the outside of each post
16
IntroductionVess A6000 Series Storage Appliance for Video Surveillance
