Pos. Order No. Description
30
1160
-
9
-
1185
Main drive motor
31
1170
-
0
-
1121
Motor bracket
32
1170
-
0
-
1501
Drive shaft worm gear
33
1170
-
0
-
1503
Worm gear
34
1170
-
0
-
1502
Supporting bock
35
1170
-
0
-
1506
Chain wheel t=12
1170
-
0
-
1504
Chain wheel t =14
1170
-
0
-
1505
Chain wheel t =16
1170
-
0
-
1102
Chain wheel t =17
1170
-
0
-
1507
Chain wheel t =18
37
2037
-
0
-
0002
Chain 6mm with coupler link
38
3000
-
9
-
4013
Splint
2,0x20 mm
39
2012
-
0
-
0013
Level switch
40
1120
-
0
-
1502
Bracket for level switch
