Pos. Order No. Description
50
1170
-
0
-
1301
Air channel
51
0170
-
0
-
1300
Heating element 230V, 1100W
52
2008
-
5
-
0007
Dryer van 220
-
240V, 50/60Hz
53
1160
-
5
-
1900
Solenoid valve
220
-
240V, 50/60Hz
54
2007
-
0
-
0015
Micro
-
rotary
-
switch for film
-
detection with operator
55
1160
-
0
-
0105
Film feed tray
56
2003
-
5
-
0002
Cartridge heater
230V, 800W
2003
-
5
-
0012
Cartridge heater
230V, 400W
57
1130
-
0
-
2101
Heat exchanger
58
2005
-
0
-
0005
Temperature safety switch mounted on heat exchanger
59
0190
-
0
-
2200
Temperature sensor
61
1170
-
0
-
1302
Channel dryer heating
62
1160
-
0
-
0801
Bracket for micro
-
rotary
-
switch
OPTIMAX
63
2027
-
0
-
0021
Strain relief
64
1160
-
0
-
0710
Hose nozzle
rubber
