PRS 500 E Instructions for use
5069-0-8002
PROTEC GmbH & Co. KG, In den Dorfwiesen 14, 71720 Oberstenfeld, Germany 10 von 47
1.2.3 Installation
NOTE
The installation of the PRS 500 E must be performed by PROTEC service department
or a service company authorized by them.
This X-ray system PRS 500 E must be installed in a shielded X-ray room that complies with the national
regulations on radiation protection.
The room intended for the installation of the X-ray system must be prepared. This may need to include
changes to the routing of electrical connections to a central distribution cabinet. The electrical and
structural design of the room intended for the generator must comply with national regulations
(electrical and floor weight load).
For more information, please see separate “Installation manual” PRS 500 E.
Contact information of persons qualified to perform installations are available upon request at:
PROTEC GmbH & Co. KG
In den Dorfwiesen 14 | 71720 Oberstenfeld
Germany
Phone: (+ 49) 7062 – 92 55 0
Fax: (+ 49) 7062 – 92 55 60
E-Mail: protec@protec-med.com
Internet: www.protec-med.com
1.2.3.1 Floor capacity
NOTE
The X-ray system is primarily made of metal pieces. This has a corresponding effect
in the weight of the device.
The X-ray system PRS 500 E has a weight of 894 kg (incl. generator).
Every technician is obliged to check the corresponding floor load before each
installation. Raised floors and hollow floors must also be considered.
1.3 Performance Characteristics
1.3.1 Height-adjustable X-ray System Table
• Variable table height
• PROGNOST E (58.9cm – 87.6 cm).
• Floating tabletop.
• Tabletop colour: white.
• Motor-operated tabletop brake for effortless patient positioning.
• Low optimised distance between the tabletop surface and the image receptor surface.
• Large adjustment range of the tabletop for positioning the patient.
• High reliability.
• Side profile rails on the long sides of the tabletop for attaching accessories.
• Prepared for the installation of an X-ray cassette holder (Bucky or Grid entity) with anti-scatter
grid and a measuring chamber for operation with an automatic exposure control.
• Variable cassette / detector sizes can be used. Formats from 13 cm x 18 cm (5" x 7") to 43 cm x
43 cm (17" x 17"), depending on analogue or digital use.
• Suitable for a Bucky or a Grid entity (analogue or digital).
