7.4 X-ray tube column
dimensions in mm
design PROGNOST SH
standard standard with telescopic arm rotation X-ray column rotation X-ray column with telescopic arm
1* Min. floor distance (vertical travel @horizontal X-
ray beam)
297 302 309 315
2*
Max. floor distance (vertical travel @horizontal X
-
ray beam)
1878 1883 1890 1896
3* Min. floor focus distance (X-ray beam to floor)
304 310 317 322
4* Max. floor focus distance (X-ray beam to floor)
1885 1891 1898 1903
5* Travel range X-ray arm - vertical
1581
6* Max. hight X-ray column
2297,5 2353
7* Max. focal spot vertical – film distance
(standard PROGNOST E):
1348,5 1354,5 1361,5 1366,5
8* Max. focal spot vertical – table top distance
(standard PROGNOST E):
1296 1302 1309 1341
X
-
ray tube support, floor stand longitudinal
travel
1412.5
X-ray tube support, floor stand longitudinal
travel, with short floor rail extension
2078.5
Extension telescopic X-ray arm (optional)
- +230 - +230
Detents X-ray tube assembly around horizontal
support arm
- 90°, 0°, + 90°, 180°
Angulation X-ray tube assembly around
horizontal support arm
+/- 180°
Detailed information please find in the enclosed User Manual, Technical Description of the PROGNOST
SH.
7.5 Vertical X-ray system image receptor stand
Standard
Column height: 2190mm
Vertical shift film center: 385mm - 1865mm
The Bucky, Grid entity and the measure chambers are connected to the generator.
Detailed information please find in the enclosed User Manual, Technical Description of the PROVERT.
