PRS 500 E
Instructions for use
5069-0-8002
PROTEC GmbH & Co. KG, In den Dorfwiesen 14, 71720 Oberstenfeld, Germany 15 von 47
2.1 General Safety Instructions
2.1.1 Requirements for Operation
WARNING!
The PRS 500 E is a protection class I device (according to EN 60601-1).
To avoid the risk of an electric shock, this device may only be connected to a
supply network with a protective earthing conductor.
The power supply for the PRS 500 E of the X-ray system is exclusively made by
direct connection to the X-ray generator or the Power Box and is permanently
connected there. The X-ray generator or the Power Box must have at least 2
connections for 230V 50/60Hz.
The X-ray generator of the X-ray system is connected to the supply network
(see technical description of the X-ray generator).
To reduce the risk of electric shock, the system must be connected to a supply
network with protective earthing.
The system does not have an on/off switch. It is switched on or off directly by
switching on the X-ray generator or by the switch on the Power Box. In order
to separate any electrical voltage from the X-ray system, the connected X-ray
generator or the Power Box must be switched off.
2.1.2 Device Operation
In case of a malfunction, do not use the PRS 500 E anymore and notify PROTEC service department or a
service company authorized by them.
2.1.2.1 Operating Type
The PRS 500 E is not intended for continuous operation.
The separate maximum operating times must be taken from the individual components.
Duty Cycle: S3 15% - maximum continuous operation of 1,5 minutes.
2.1.3 Operating Personnel
NOTE
Only trained and authorized personnel are allowed to work on the PRS 500 E.
NOTE
The operating personnel must be familiar with all warning signs attached to the PRS
500 E. They are used for your own safety and that of others and ensure proper
operation.
