PRS 500 E Instructions for use
5069-0-8002
PROTEC GmbH & Co. KG, In den Dorfwiesen 14, 71720 Oberstenfeld, Germany 33 von 47
6 Power Supply
NOTE
The X-ray system requires the following power supply depending on the generator
(see table „Power Supply Generator”).
Generator Type Output Power Line Voltage Phases Line Frequency Line Resistance Fuse
HFe 501 50 kW 400 VAC 3 phases 50/60 Hz 0.3Ω 35 A time delay
HFe 601 65 kW 400 VAC 3 phases 50/60 Hz 0.2Ω 50 A time delay
HFe 801 80 kW 400 VAC 3 phases 50/60 Hz 0.12Ω 50 A time delay
Venus-32-R 1-ph 32 kW
220 VAC
230 VAC
1 phase 50/60 Hz 0.5 Ω 16 A time delay
Venus-32-R 3-ph 32 kW
380 VAC
400 VAC
3 phases 50/60 Hz
0.27 Ω
0.29 Ω
63 A time delay
Venus-50-R 1-ph 50 kW
220 VAC
230 VAC
1 phase 50/60 Hz 0.5 Ω 16 A time delay
Venus-50-R 3-ph 50 kW
380 VAC
400 VAC
3 phases 50/60 Hz 0.17 Ω 63 A time delay
Polydoros RFX 55 55 kW
380 VAC
400 VAC
440 VAC
480 VAC
3 phases 50/60 Hz
0.15
Ω
0.17 Ω
0.20 Ω
0.24 Ω
50 A gG
Polydoros RFX 65 65 kW
380 VAC
400 VAC
440 VAC
480 VAC
3 phases 50/60 Hz
0.15 Ω
0.17 Ω
0.20 Ω
0.24 Ω
50 A gG
Polydoros RFX 80 80 kW
380 VAC
400 VAC
440 VAC
480 VAC
3 phases 50/60 Hz
0.10 Ω
0.11 Ω
0.14 Ω
0.16 Ω
50 A gG
CMP 200 DR 50 50 kW
400 VAC
480 VAC
3 phases 50/60 Hz
0.17
Ω
0.24 Ω
60 A time delay
CMP 200 DR 65 65 kW
400 VAC
480 VAC
3 phases 50/60 Hz
0.13 Ω
0.19 Ω
60 A fast acting
CMP 200 DR 80 80 kW
400 VAC
480 VAC
3 phases 50/60 Hz
0.10 Ω
0.15 Ω
60 A fast acting
Table Power Supply Generator
WARNING!
To avoid the risk of an electric shock, this device may only be connected to a
supply network with a protective earth conductor.
6.1 Electromagnetic Compatibility (EMC) after EN 60601-1-2
CAUTION!
As a medical electrical device, the PRS 500 E is subject to special
precautionary measures regarding EMC and must be installed and
commissioned in accordance with the EMC information contained in the
accompanying documents.
CAUTION!
Portable RF communication devices (radio devices) should not be used closer
than 30 cm (12 in) to the marked parts and cables of the PRS 500 E. Failure to
observe can lead to a reduction in the performance characteristics of the
device.
