PRS 500 E
Instructions for use
5069-0-8002
PROTEC GmbH & Co. KG, In den Dorfwiesen 14, 71720 Oberstenfeld, Germany 43 von 47
Caution: pinch-/crushing hazard for hands and fingers
Caution: pinch-/ crushing hazard of feet
Climbing forbidden
Attention: Electrostatic sensitive devices
Do not exceed the maximum indicated weight
Do not exceed the maximum indicated weight
Tabletop movements for exposure
Longitudinal movement of the tabletop
Transverse movement of the tabletop
Table height adjustment – table up
Table height adjustment – table down
Release tabletop brakes
Horizontal movement of the X-ray system tube support, floor
stand
Vertical movement of the X-ray tube arm
Rotation of the X-ray tube assembly
