Proton Products SL mini and SLR mini Series Speed and Length Gauges Instruction Manual - issue 1s
OUTPUT PARAMETERS
1 DW word = 2 bytes 2013.08.26
DW
Bit
Comments
Units
Range/Remark
0
0
Mode
0=Normal
1=Batch
1
Length / speed resolution
0=Length 0.1 / speed 0.01
1=Length 0.0001 / speed
0.001
2
Not used
3
Measured length >= Preset1
1=>Preset
4
Measured length >= Preset2
1=>Preset
5
Length reset
0=Reset
6
Measurement unit
0=Metres
1=Feet
2=Yards
3=other unit (set on PCIS)
7
8
Speed signal output response
0=Averaged
1=Instantaneous
9
10
Laser status
1=Laser on
0=Laser off
11
Gauge OK
1=Gauge OK
12
Speed reading validity
1=Valid
0=Invalid
13
Object detected
1=Object detected
0=No object
14
Good reading status
1=Lower than threshold
0=OK
15
Not used
1
0
Gauge OK
1=Error
0=OK
1
Laser temperature too high
1=Too high
0=OK
2
Laser temperature too low
1=Too low
0=OK
3
APD temperature too high
1=Too high
0=OK
4
APD temperature too low
1=Too low
0=OK
5
APD DC level
1=Too high
0=OK
6
Gauge too hot
1=Too hot
0=OK
7
Not used
8
Not used
2
Average speed
Old format: 1=0.01m/min {ft/min} {yds/min}
New format: 1=0.001m/min{ft/min}{yds/min}
±10~999999
(0.10~9999.99)
3
4
Instant speed
±10~999999
(0.10~9999.99)
5
6
Total length / Batch length (when in
batch mode)
Old format: 1=0.1m{ft}{yds}{inch}
New format: 1=0.0001m{ft}{yds}{inch}
±200,000.0000
7
8
Logic input
0
Not used
1
Direction
0=Count up
1=Count down
2
Logic input 1 function
0=Direction
1=Length hold
2=Display hold
3=Speed hold
3
4
Logic input 1 state
1=Active
5~7
8
Logic input 2 function
0=Reset input
1=Length hold
9
10
Logic input 2 state
1=Active
11
Direction
0=Count up
1=Count down
12
Length hold
1=Hold
13
Display hold
1=Hold
14
Speed hold
1=Hold
