Proton Products SL mini and SLR mini Series Speed and Length Gauges Instruction Manual - issue 1s
OPTICAL WINDOW CLEANING PROCEDURE
The optical window is manufactured from anti-reflection coated optical glass; it must be
treated with the same level of care as a high-performance camera lens.
Before inspecting or cleaning the optical window, ensure that the gauge is powered
off, the LSR_EN key-switch is locked out and no laser light is emitted.
1. Use the small blower brush to remove any visible dust on the optical window.
2. Apply a few drops of lens cleaning solution to a fresh lens cleaning tissue or a clean micro-
fibre lens cleaning cloth.
3. Gently wipe the optical window from the centre outwards; apply only light pressure to the
tissue or cloth when wiping the optical window.
4. Repeat as necessary with fresh tissues or a clean section of cloth until the optical window is
clean and free of all smears and smudges.
INSTALLATION SEQUENCE
Unpack the gauge and check for missing accessories and shipping damage.
Mechanical installation:
1. Mount the gauge securely either on a user supplied mount or on an optional Proton Products
mounting plate.
Electrical installation:
1. Install earth connections.
2. Connect the gauge to an optional Proton Products PSU-BOB mini power supply and break-
out box.
3. Install laser safety connections (laser enable, shutter enable and shutter status).
4. Install communications interface connections (RS-232, Ethernet or optional PROFIBUS,
PROFINET, EtherNet/IP or DeviceNET).
5. Install electrical interface connections (logic inputs, logic outputs, pulse outputs) using the
optional Proton Products PSU-BOB mini breakout box or terminal strip.
6. Connect a PC installed with the PCiS_SLmini software to the gauge via the RS-232, Ethernet
or optional PROFINET or EtherNet/IP communications interface.
7. Configure the gauge using the PCiS_SLmini software.
