Proton SL mini 3060 User Manual

Page 107 of 126
Proton Products SL mini and SLR mini Series Speed and Length Gauges Instruction Manual - issue 1s
Pin
Designation
Comment
PC DB9 serial
port pin
7
CTS1
Not used
8
RTS1
Not used
S
Shield
Ensure that the cable shield is connected to this via the plug
shield connection.
Shield
The above table also shows the configuration of a cable for connection to a personal computer (PC)
type DB9 serial port.
I-BUS
Connector type: DB9 female (socket)
PROFIBUS
Pin
Function
Comments
3
B
5
GND
6
+5V
8
A
S
Shield
Ensure that the cable shield is connected to this via the plug shield connection.
DeviceNet
Pin
Function
Wire colour
Comment
3
CANL
Blue
5
V-
Black
6
V+
Red
8
CANH
White
S
Shield
Ensure that the cable shield is connected to this via the plug
shield connection.
Ethernet / EtherNet/IP / PROFINET
Pin
Function
Comments
1
LAN TX-
2
LAN TX+
7
LAN RX-
9
LAN RX+
S
Shield
Ensure that the cable shield is connected to this via the plug shield connection.
Note: for Ethernet, EtherNet/IP and PROFINET communications interfaces, the i-BUS DB9 socket
and RJ45 socket are wired in parallel; either one or the other connector may be used depending on
the available cable plug type.
RJ45 SOCKET
Connector type: RJ45 8P8C female (socket)
Ethernet / EtherNet/IP / PROFINET
Pin
Function
Comments
1
LAN TX+
2
LAN TX-
3
LAN RX+
6
LAN RX-
S
Shield
Ensure that the cable shield is connected to this via the plug shield connection.
Note: for Ethernet, EtherNet/IP and PROFINET communications interfaces, the i-BUS DB9 socket
and RJ45 socket are wired in parallel; either one or the other connector may be used depending on
the available cable plug type.
