Proton Products SL mini and SLR mini Series Speed and Length Gauges Instruction Manual - issue 1s

Pull-down

Pull-up

Logic inputs configuration

Each individual logic input can be independently configured for both active state polarity and function.

Configuration via the PCiS_SLmini software:

Click the “Interface” button on the main page:

When prompted, enter 64000 for the password and click the “OK” button:

+15V

DGND

5.1kΩ

+15V

DGND

5.1kΩ

8β0Ω

From PLC

Active High

Logic Output
