ULTRA 3 INSTRUCTION MANUAL
108
Application Parameters
Operation
P100 Mode of Operation
This parameter sets the mode of operation, when in run mode, and can be
set to one of the following:
OPTION
DESCRIPTION
When Ultra Wizard = 1 Level/Volume, 2 Pump or 3 Flow
1 = Distance (Default)
Display shows the distance from the transducer face
to the surface of the material measured.
2 = Level
Shows how full a vessel is.
3 = Space
Shows how empty a vessel is.
When Ultra Wizard = 1 Level/Volume
5 = Volume
Display shows volume of the vessel
When Ultra Wizard = 3 Flow
4 = OCM Head
Display shows how high the head is.
5 = OCM Flow
Display shows the instantaneous flow
P101 Xducer (Transducer)
This parameter should be set to the transducer being used with the unit, and
can be set to one of the following:
OPTION
DESCRIPTION
When Ultra Wizard = 1 Level/Volume, 2 Pump
1 = dB3
Transducer is a dB3. Range = 0 to 3 metres
2 = dB6 (default)
Transducer is a dB6. Range = 0.3 to 6 metres
3 = dB10
Transducer is a dB10. Range = 0.3 to 10 metres
4 = dB15
Transducer is a dB15. Range = 0.5 to 15 metres
7 = dBS6
Transducer is a dBS6. Range = 0.2 to 6 metres
8 = dBMach3
Transducer is a dBMach3. Range 0.3 to 1.50 metres
When Ultra Wizard = 1 Level/Volume
5 = dB25
Transducer is a dB25. Range 0.60 to 25 metres
6 = dB40
Transducer is a dB40. Range 1.2 to 40 metres
OPTION
DESCRIPTION
