ULTRA 3 INSTRUCTION MANUAL
124
P213, P223, P233 - Relay Setpoint 3
This parameter is used to determine the Limit Time between each Drive
Period. Relay Setpoints are entered in Minutes, during which time the relay
will remain OFF.
See the appropriate relay Function tables (P211, 221, 231) for further
information.
Miscellaneous
P210, 220, 230, 240, 250, 260, 270, 280, 290, 570 = 4 (Miscellaneous)
When a relay is set to be a miscellaneous relay, the second parameter
determines its function.
P211, 221, 231, 241, 251, 261, 271, 281, 291, 571 – Relay Function
This function allows the relay to work in relation to a clock or a specific event
and will be set to activate in relation to Real Time.
Relay is always de-energised
Relay will energise ON at a specified time each day as set
in Relay Setpoint 1 (P213, 223, 233). And turns OFF, de-
energises, after the specified-On Time period as set in
Relay Setpoint 2 (P214, 224, 234)
When Ultra
Wizard = 3 Flow
then
2 = Totaliser
Relay will energise ON momentarily each time the
specified flow has passed as set in Relay setpoint 1 (P213,
223, 233), this parameter sets the multiplication factor
which will be applied to the on board totaliser (P820) to
determine the switch point of the relay. E.g. if the totaliser
is set to totalise in cubic metres and the relay is required
to provide a closure every 10,000 litres Relay setpoint 1
would be set to 10. Relay setpoint 2 (P214, 224, 234) can
be used to select the time the relay will remain closed in
seconds.
Important Notice
When using a Relay to control a device at a specified time of day ensure
that the Time P932 is set correctly. And if required, enable Daylight
Saving for the appropriate time difference P970 – P979.
