Pulsar Measurement Ultra 3 User Manual

PULSAR MEASUREMENT
43
CHAPTER 4 ULTRA WIZARD
The Ultra Wizard menu allows you to turn Ultra 3 into anyone of three
dedicated ultrasonic devices to exactly suit the requirements of your
application.
Enter Program Mode
First you need to go from run mode into program mode. Assuming the
passcode is the default 1997, then you should enter the following on the
keypad:
Choose Ultra Wizard
Now you need to go into the quick setup. You will see on the menu the
words ‘Quick Setup’, which is the first item on the menu system. Try pressing
the two arrow keys to see some more menu options, but return to Quick
Setup, and press
1 = Level or Volume measurement (Level/Vol)
2 = Pump Control (Pump)
3 = Open Channel Flow measurement (Flow)
APPLICATION
UNIT TYPE
1 = Level/Vol
When selected the Ultra 3 is configured as a Level Star 3
2 = Pump
When selected the Ultra 3 is configured as a Vantage 3
3 = Flow
When selected the Ultra 3 is configured as a Flow 3
ENTER
1
9
9
7
ENTER
This takes you to the ‘Select Application
Menu, and provides a choice of:
