PULSAR MEASUREMENT
13
ECHO PROCESSING
Description
DATEM (Digital Adaptive Tracking of Echo Movement)
OUTPUTS
Analogue I/O
Isolated (floating) output (to 150V) of 4-20 mA or 0-20
mA into 500 (user programmable and adjustable)
0.1% resolution
Digital output
Full Duplex RS232
Volt free contacts, number, and
rating
3 form "C" (SPDT) rated at 5A at 240V AC
Display
6 digits plus 12-character text, plus bar graph with
direction indicators, remote communicator identifier,
and program/run/test mode indicators
PROGRAMMING
On-board programming
By integral keypad
PC programming
Via RS232
Remote programming (Rack and
panel option only
By optional infra-red communicator
Programming security
Via passcode (user selectable and adjustable)
Programmed data integrity
Via non-volatile RAM, plus backup
SUPPLY
Power Supply
115VAC +5% / -10% 50/60 Hz,
230VAC + 5% / -10% 50/60 Hz,
dc 18 - 30V
10W maximum power (typically 6W)
Fuses
100mA at 230V AC (fitted as standard to wall units)
200mA at 115V AC (fitted as standard to fascia units)
ECHO PROCESSING
Batteries
2 x AA alkaline batteries. Do not use NiCad’s
Pulsar Measurement operates a policy of constant development and
improvement and reserve the right to amend technical details, as necessary.
