PULSAR MEASUREMENT
57
To program the Level Star for Example 3 Volume Application with Control
by using the Quick Setup menu proceed as follows. If required access the
Program Mode and key in the passcode 1997 and press ENTER.
Using the ‘right’ arrow key, go to the Quick Setup menu press ENTER and
as prompted, by the questions, select the relevant option and ENTER.
Programming is now complete, and the unit can be returned to the run
mode, press CANCEL until Run Mode? Is displayed on the LCD press
ENTER, and the Ultra 3 will return to the Run Mode.
QUESTION
OPTION
Level/Volume
1 = Level App.
Control
1 = Control down
No. of controls
1 = 1 Relay
Control no.1
1 = Set to relay 1
No. of alarms
2 = 2 Alarms
Type alarm 1
1 = High
Alarm no.1
1 = Set to relay 2
Type alarm 2
2 = Low
Alarm no.2
The unit knows that only Relay 3 is
available and so will automatically set
Alarm 2 to Relay 3.
Xducer (P101)
2 = dB6
Material (P102)
1 = Liquid
Measurement units (P104)
1 = Metres
Empty Level (P105)
3.5m
Span (P106)
2.8m
Vessel shape (P600)
0 = Cylindrical flat base
Vessel dimensions
Enter vessel dimensions as requested
(depends on vessel shape chosen)
Volume units
Select as required
Max Volume (Read only)
Displays the Max volume as calculated
by the Ultra 3
