ULTRA 3 INSTRUCTION MANUAL
82
To program the Ultra 3 for Example 1 V-Notch Weir by using the Quick
Setup menu proceed as follows. If required access the Program Mode, key
in the passcode 1997 and press ENTER
Using the ‘right’ arrow key, go to the Quick Setup menu press ENTER and
as prompted, by the questions, select the relevant option and press ENTER.
Programming is now complete, and the unit can now be returned to the run
mode, press CANCEL until Run Mode? Is displayed on the LCD press
ENTER, and the Flow Oracle 160 will return to Run Mode.
QUESTION
OPTION
PMD Type
1 = Exponent
Exponent
6 = V-Notch
Calculation
2 = Ratiometric
No. of alarms
0 = No alarms
Xducer
1 = dB Mach3
Volume units
1 = Litres
Time units
1 = Per second
Measurement units
1 = metres
Empty Level
1.00 metres
Minimum head
0.00 metres
Maximum head
0.40 metres
Totaliser enable
1 = On
Totaliser (R)
0 = No
Totaliser multiplier
7 = 1,000
Max flow
96.5
