P213 (Relay 1), P223 (Relay 2) - Relay “ON” Setpoint
This parameter determines the “ON” point for the control relay and should
be set as follows, in Measurement Units P104
P214 (Relay 1), P224 (Relay 2) - Relay “OFF” Setpoint
This parameter determines the “OFF” point for the control relay and should
be set as follows, in Measurement Units P104
CONTROL DOWN
CONTROL UP
P213/P223 “ON” Setpoint
P213/P223 “ON” Setpoint
Higher than
Lower than
P214/P214 “OFF” Setpoint
P214/P224 “OFF” Setpoint
CONTROL DOWN
CONTROL UP
P214/P224 “OFF” Setpoint
P213/P223 “OFF” Setpoint
Lower than
Higher than
P214 “OFF” Setpoint
P214 “OFF” Setpoint
