IMP+ INSTRUCTION MANUAL
10
CHAPTER 2 INSTALLATION
Unpacking
Power Supply Requirements
The IMP+ operates from a DC supply of 11 –30V and will typically draw less
than 0.06A.
The compact one-piece construction of the IMP+ can be mounted easily
using the integral nose thread (1.5" or 2" BSP/ NPT, dependent on model).
When choosing a location to mount the Imp, bear in mind the following:
• For access to the LCD display and programming buttons it is
recommended that you mount it in an area which is easily accessible.
• The ultrasonic signal path should be free of falling material and
obstructions such as pipes, beams etc.
• The IMP 3 should be mounted at least 20cm (0.66 feet) above the
maximum level of the material and be perpendicular to the surface.
Whilst the IMP 6 and 10 should be mounted at least 30cm (0.98 feet)
above the maximum level of the material and be perpendicular to the
surface.
• The ambient temperature is between -20ºC and 65ºC.
• There should be no high voltage cables or electrical inverters close by.
Important Notice
All shipping cartons should be opened carefully. When using a box cutter,
do not plunge the blade deeply into the box, as it could potentially cut or
scratch equipment components. Carefully remove equipment from each
carton, checking it against the packing list before discarding any packing
material. If there is any shortage or obvious shipping damage to the
equipment, report it immediately to Pulsar Measurement.
Important Notice
All electronic products are susceptible to electrostatic shock, so follow
proper grounding procedures during installation.
