Pulsar IMP+ User Manual

PULSAR MEASUREMENT
7
Product Specification
PHYSICAL
Dimensions
O/A height186mm x O/A diameter 133mm (5.24” x
7.32”)
Mounting
1.5” BSP/NPT (IMP3 and 6 models) 2” BSP/NPT
(IMP10)
Weight
Nominal 1 kg
Cable entry detail
2 off cable glands 4.5 – 10mm. (torque to 2NM)
ENVIRONMENTAL
IP Rating (Wall)
IP67
Max. & min. temperature
(Ambient)
-40ºC to +65ºC (-4ºF to 149ºF)
Max. & min. temperature
(Transducer)
-40ºC to +80ºC (-4ºF to 176ºF)
CE Approval
See EU Declaration of Conformity
PERFORMANCE
Beam angle (-3dB half power)
<10° inclusive
Operating frequency
IMP 3 125kHz, IMP 6 75kHz, IMP 10 41kHz
Range
IMP 3 0.2 – 3m (0.66 – 10ft)
IMP 6 0.3 – 6m (0.98 – 20ft)
IMP 10 0.3 – 10m (0.98 – 33ft)
Accuracy
± 0.25% or 6mm (0.24 inches) whichever is greater
Resolution
± 0.1% or 2mm (0.08inches) whichever is greater
4-20mA output
Resolution 5µA
Temperature compensation
Via internal temperature sensor (± 0.5°C accuracy)
Response time
Power up to stable reading = 10 seconds
2-wire configuration (isolated)
Passive 4-20mA output
Current output
3.5-22mA
3-wire configuration (non-
isolated)
0-10V analogue output.
Active and passive 4-20mA outputs.
Backlit LCD display
Power consumption with relays
energised
<60mA (less 12mA/relay not energised)
PROGRAMMING
PC Programming
Via RJ11 port to RS232 using IMP PC software
On-board programming
Via 4 button keypad and a 4-digit LCD display

Pulsar IMP+ Specifications

General

Brand	Pulsar
Model	IMP+
Category	Measuring Instruments
Language	English
