Pulsar IMP+ User Manual

PULSAR MEASUREMENT
41
P842 Voltage Output
This parameter will determine the range of the voltage output. The voltage
output will automatically be scaled to represent the Span P106 where
0volts represents 0% (empty) and maximum voltage 5 or 10 volts,
depending on range selected, will represent 100% (full).
OPTION
DESCRIPTION
0 = 5 volts
Voltage output range will be 0 – 5 volts
1 = 10 volts
Voltage output range will be 0 – 10 volts
Compensation (CoP) Menu
P851 Measurement Offset
The value of this parameter is added to the measured distance, in
Measurement Units (P104).
This Offset will be added to the level, as derived from the transducer, and
will affect everything including the reading on the display, the relay
setpoints and the mA output.
P852 Temperature Source
This parameter determines the source of the temperature measurement. By
default, it is set to internal (transducer) (P852=1), which will automatically
detect the temperature from the transducer. If for any reason, no
temperature input is received, then the Fixed Temp value is used, as set by
P854.
The temperature source can be specifically set as follows:
OPTION
DESCRIPTION
1 = Internal (Default)
Always uses temperature reading from transducer.
3 = Fixed
Always uses fixed temperature (P854)
P854 Fixed Temperature
This parameter sets the temperature, in degrees centigrade to be used if
P852 (Temperature Source) =3. Default = 20
o
C
Important Notice
In the event of a failsafe condition occurring, the voltage output will fail in
accordance with the Failsafe Mode P808
