Chapter 8 Parameter Listing and Descriptions
Application Parameters
Operation
P100 Mode of Operation
This parameter sets the mode of operation, when in run mode, and can be set
to one of the following:
Option
Description
When Ultra Wizard = 1 Level/volume, 2 Pump or 3 Flow
1 = Distance (Default)
Display shows the distance from the
transducer face to the surface.
2 = Level
Display shows how full the vessel is.
3 = Space
Display shows how empty a vessel is.
When Ultra Wizard = 1 Level/Volume
5 = Volume
Display shows volume of the vessel.
When Ultra Wizard = 3 Flow
4 = OCM Head
Display shows how high the head is.
5 = OCM Flow
Display shows the instantaneous flow.
P101 Xducer (Transducer)
This parameter should be set to the transducer being used with the unit, and
can be set to one of the following:
Option
Description
When Ultra Wizard = 1 Level/volume, 2 Pump
1 = dB3
Transducer is a dB3. Range 0.410 to 9.843 feet
2 = dB6 (Default)
Transducer is a dB6. Range 0.984 to 19.685 feet
3= dB10
Transducer is a dB10. Range 0.984 to 32.808 feet
4= dB15
Transducer is a dB15. Range 1.640 to 49.213 feet
7 = dBS6
Transducer is a dBS6. Range 0.656 to 19.685 feet
8 = dBMach3
Transducer is a dBMach3. Range zero to 7.956 feet
When Ultra Wizard = 1 Level/Volume
5= dB25
Transducer is a dB25. Range 1.969 to 82.021 feet
6 = dB40
Transducer is a dB40. Range 3.937 to 131.234 feet
