Pulsar Ultra 3 (UL) - Totaliser

Page 162
P813 Control Messages
This parameter determines whether notification messages are displayed on
the auxiliary line of the display in run mode when a control relay is switched
on or off. The message is in the form “Time ON”.
Option
Description
0 = No (Default)
Control messages will not be displayed
1 = Yes
Control messages will be displayed
P814 Miscellaneous Messages
This parameter determines whether notification messages are displayed on
the auxiliary line of the display in run mode when a miscellaneous relay is
switched on or off. The message is in the form “Clock ON”.
Option
Description
0 = No (Default)
Misc. messages will not be displayed
1 = Yes
Misc. messages will be displayed
P816 Totaliser (R)
When Ultra Wizard = 3 Flow
This parameter determines whether or not the resettable totaliser will be
displayed in the auxiliary line of the display in run mode. When selected,
the auxiliary display will scroll between the resettable totaliser and the
totaliser units selected. Default = 0 (Off).
The resettable totaliser can be reset while in run mode via the “Totaliser”
hot key by pressing “0” while Total (R) is displayed.
Totaliser
When Ultra Wizard = 3 Flow
P820 Totaliser
Displays the current value of the, non-resettable totaliser. During run mode,
this totaliser can be viewed via the “Totaliser” hot key, . Unlike the
resettable totaliser this totaliser cannot be reset while in run mode, it can
however be reset while in program mode by accessing P820 Totaliser and
entering zero.
