Page 36
Lev/Volume
If you require to set up a level or volume application, with or without a
choice of control functions then press “1” followed by “ENTER” the
message “Loading ***” will be displayed and your Ultra 3 will be
configured as a Level Star 3. Confirmation that configuration has been
completed will be given by the unit type, software version and serial number
being displayed briefly on the LCD and the unit advancing to the relevant
“Quick Setup” menu.
For full details on how to programme the Level Star 3, using the Quick
Setup Menu, please proceed to Chapter 5 Level/Volume. For a full
description of all features and parameters please refer to Chapter 8
Parameter Listing and Description.
Level Star 3
The Level Star provides the ability to convert level measurement to enable
the contents of a vessel to be displayed in volume, along with control
functions, for a complete range of vessel shapes. Also available within the
unit is a customised 32 point calibration routine which also permits the
calculation of volume in non - standard vessels.
The Level Star 3 can measure from zero to 131 feet from the face of the
transducer to the surface being monitored, dependent on the transducer used.
The Level Star 3 can show details of level, space, distance, and units of
volume on the display.
The three user-definable relays with individual setpoints can be programmed
to activate devices such as pumps or other control equipment.
The 4-20 mA output is fully programmable to provide an output relative to
level, space, distance or volume of the application being measured.
Pump
If you require to set up a pump application, then press “2” followed by
“ENTER” the message “Loading ***” will be displayed and your Ultra 3
will be configured as a Vantage 3. Confirmation that configuration has been
completed will be given by the unit type, software version and serial number
being displayed briefly on the LCD and the unit advancing to the relevant
“Quick Setup” menu.
For full details on how to programme the Vantage 3, using the Quick Setup
Menu, please proceed to Chapter 6 Pump. For a full description of all
features and parameters please refer to Chapter 8 Parameter Listing and
Description.
