Pulsar Ultra 3 (UL) User Manual

Page 164
Bargraph
When Ultra Wizard = 3 Flow
P829 Bargraph
By default, the bar graph will be representative of, as a percentage, the
reading obtained, as determined by the Mode P100. This parameter is
automatically set to the correct default option when selecting the Mode
P100, but can be changed if required. The options are as follows:
Option
Description
1 = Level
Bargraph will be representative of level.
2 = Head (Default)
Bargraph will be representative of head.
3 = Flow
Bargraph will be representative of flow.
mA Output Parameters
Range
P830 mA Range
This parameter determines the range of the mA output, from the following.
Option
Description
0= Off
mA output disabled.
1= 0 to 20 mA
mA output directly proportional to the mA mode
(P831), so if the reading is 0% the output is 0 mA. If
the reading is 100% the output is 20 mA.
2= 4 to 20 mA
(Default)
mA output directly proportional to the mA mode
(P831), so if the reading is 0% the output is 4 mA. If
the reading is 100% the output is 20 mA.
3= 20 to 0 mA
mA output inversely proportional to the mA mode
(P831), so if the reading is 0% the output is 20 mA. If
the reading is 100% the output is 0 mA.
4= 20 to 4 mA
mA output inversely proportional to the mA mode
(P831), so if the reading is 0% the output is 20 mA. If
the reading is 100% the output is 4 mA.
