Note
If you have already setup a common application, then there will be a number
shown other than 0, and you will see messages showing what the current
setup is. If you want to reset this and start again, press 0 (which will reset all
the quick setup parameters), otherwise pressing ENTER will allow you to
edit the parameters that have been set.
Choose Your Application
There are two categories of application, which are all described later in this
chapter. They are level or volume all with the choice of control functions
and alarms.
If you want to set-up a basic level monitoring application, as described in
the following example 1, then choose 1.
If you want to set-up a level monitoring application with control relays, as
described in the following example 2, then choose 1 and choose either
control down (press 1) or control up (press 2).
If you want to set-up a volume application, as described in the following
example 3, then choose 2.
Once you have chosen your application you will be asked a series of
questions which are answered by choosing the appropriate option as detailed
in the flow chart below. Once all the questions have been answered you will
be prompted to provide further information, as detailed in the tables below,
in order to complete the programming of the unit.
